Jazzy® Elite HD
Jazzy® Elite HD
$5,459.00
FULFILLMENT OPTIONS
This item can be shipped
DESCRIPTION
Experience the power and versatility of the Jazzy® Elite HD. Large front wheels absorb and climb, easily tackling life’s everyday obstacles. An intuitive hand control ensures effortless operation and simple maneuvering.
*Pride® FDA Class II Medical Devices are designed to aid individuals with mobility impairments
- 450 lbs. weight capacity
- Up to 4 mph maximum speed
- 24" turning radius
- Up to 14.4 miles per charge
- Comfortable, depth-adjustable, limited recline high-back seat with headrest
- Easy rear access to batteries
- Intuitive controller is easy to operate
- Color-through shroud
- Angle-adjustable foot platform offers greater comfort
- Front-wheel drive design for excellent maneuverability
- 14" knobby tires and optimum weight distribution provide superior traction
- 40A Dynamic LiNX controller
- Extended 13-month limited warranty
- HCPCS Code: Group 2 Heavy Duty (K0824/K0825)
| CATEGORY | SPECIFICATION |
|---|---|
| Model |
Jazzy® Elite HD |
| Weight Capacity | 450 lbs. |
| Turning Radius1 | 24" |
| Width1 | 24.25" |
| Length1,2 | 35.5" |
| Maximum Speed3 | Up to 4.0 mph |
| Ground Clearance1 | 3" |
| Front Wheels | 3" solid anti-tips |
| Drive Wheels | 14" foam filled |
| Rear Wheels | 6" solid casters |
| Drivetrain | Two motor, front-wheel drive |
| Braking System | Regenerative and electro-mechanical) |
| Suspension Type | Limited |
| High-Back Seat (max. size) | 24"W x 24"D |
| High-Back Seat-to-Floor Range | 20” – 22” |
| Synergy® Seating | 24”W – 24”D |
| Synergy® Seat-to-Floor Range | 15.75” – 17.75” |
| Standard Electronics | 50 A Dynamic |
| Battery Size (2 required) | 12 volt, NF-22 |
| Standard Battery Charger | 5A, off-board |
| Per-Charge Range3,7 | Up to 14.4 miles |
| Battery Weight6 | 37 lbs. each |
| Weight of Heaviest Piece4 | 99 lbs. |
| Standard Seat Weight | 18" wide - 51.8 lbs. 20" wide - 54 lbs. 22" wide - 57.6 lbs. |
| Standard Seat Size | 20" x 18"-20" |
| Medicare Code Coverage | Group 2 Heavy Duty (K0824/K0825) |
| Warranty | 5-year limited on frame; 13-month limited on electronics; 13-month on drive motors; 13-month limited on batteries. |
| Notes: 1 Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of + or - 3 %. Dimensions listed are for power base only. Overall measurements will vary based on seating and accessory selections. 2 Without front riggings. 3 Varies with user weight, terrain, battery type, battery condition and tire pressure. 4 Does not include seat or battery weights. 5 Maximum weight capacity is reduced to 400 lbs. (181 kg) on 18" deep seat configurations. 6 Battery weight may vary based on manufacturer. 7 Tested in accordance with ANSI/RESNA, WC Vol. 2, Section 4 and ISO 7176-4 standards. Results derived from theoretical calculations based on battery specifications and drive system performance. Testing conducted at maximum weight capacities. This specification can be subject to a variance of +10%, -5%. |
|
| The information contained herein is correct at the time of publication; we reserve the right to alter specifications without prior notice. | |
